GIMIDO Regular Coils fit HE Ti Nail or Quartz Banger Nail. Use NiChrome(Ni80Cr20) Resistance Wire.
This Coil Diamter is 15.8mm,16mm or 20mm.Height is 12.7mm;120V100W or 230V150W;
Heat up 710F immediately, Less than 1 minutes. Long work Life Design. Made in China.
Best NiChrome(Ni80Cr20) Resistance Wire.
- Ni80Cr20 Resistance Wire
- Pure MgO Tube insulation
- SUS321 as sheath material
- 120V100W or 230V150W, if you need customize wattage, please shoot notes to us, same price, but need to wait 2~5 days.
- 10mm,15.8mm,16mm,20mm sizes available
Simple setup and operation
- Regular Coil touch tight with the Ti Nail.
- 12.7mm Height fit HE Ti nail.
- 5 Pin XLR Plug
- 1500mm Metal Length
- Heat up to 710F fastly
XLR Diagram(Default fit D-Nail Units), Other Diagram available if you tell us.
- Pin1,Pin2 are power for coil
- Pin3 is TC+
- Pin4 is TC-;
- Pin5 is ground wire
